SEA BOX | 20’ x 8’6” ISO Containerized Medical Shelter

20’ x 8’6” ISO Containerized Medical Shelter

Part Number: SB861.6.MED-HAB

Type: I

Partitioned into bathroom, examination room, and office. Comes with plumbing, desk, and personnel door on one side.

If your storage or transportation needs are more unique, SEA BOX can create custom sized containers to accommodate any need.
Request a Quote
  • Medical exam table
  • (2) Stainless steel wall sinks
  • Mirrors with shelf
  • China toilet
  • Desk area with file cabinets
  • Friedrich air conditioning unit
  • Small refrigerator
  • Fluorescent lighting
  • Tile floor
  • Fiberglass panels on interior walls
  • R-11 insulation in walls and ceiling
  • 100 amp electrical panel
  • Exhaust fan
  • Smoke and heat detector
ALL NEW CONTAINERS ARE MANUFACTURED TO THE LATEST ISO STANDARD
Length Height Width Door Opening
Exterior Interior Exterior Interior Exterior Interior Height Width
Ft in 20’ 0” 19’ 1” 8’ 6” 7’ 10 1/4” 8’ 0” 7’ 2 1/2” 7’ 5 11/16” 7’ 8 11/64”
Metric 6,096 5,816 2,591 2,394 2,438 2,438 2,278 2,341
TARE WEIGHT PAYLOAD GROSS WEIGHT CUBIC CAPACITY
Lbs
Kgs

ALL DIMENSIONS AND WEIGHTS ARE NOMINAL AND SUBJECT TO MINOR VARIATIONS THAT MAY OCCUR DURING THE MANUFACTURING PROCESS
